CommonSENSE Software toolkit for image processing

dostępność:

Cena:

Pobierz kartę produktu »

Opis
Dane techniczne
Informacje
W komplecie
Kalkulator projekcji

In today's military environments, quick and immediate access to visual information is of vital importance. However, turning mission-critical information into real-time knowledge typically requires extensive customization on the client's application programs.

Barco's CommonSENSE software toolkit offers a comprehensive application programming interface to help system designers with the rapid development of high-performance visualization applications. Combined with Barco's network client application for enhanced C4ISR, CommonSENSE enables operators in the field to connect and respond to mission-critical information anytime, anywhere.

Offered as an option to Barco's Display Processing Modules (DPM) and smart displays, CommonSENSE can be deployed into a variety of manned positions for mission-critical systems, including unmanned vehicle systems, ground army vehicles and naval C4ISR systems.

Benefits:

Simplifies application development to reduce cost and speed time-to-market
Enables technology refresh of hardware with no impact to application software for reduced lifecycle cost and platform stability
Preserves video information (frames, pixels) while performing complex manipulations in real time
Frees CPU of image processing to perform other operations

Features

Capabilities

Full motion video (FMV)

Selection of any video, networked video or graphics source for processing, image composition and display
Controls for adjusting camera inputs (including brightness, contrast, saturation, edge alignment, and multiple de-interlacing modes
Positioning and sizing of video on the screen (including Picture-in-Picture)
Specification of how video content should be displayed, according to region of interest or pan, zoom and rotate parameters

Integration with graphics

References, tags and highlights to visualize content of interest
Metadata overlay
Integration with graphics applications, e.g. 3D video mapping, synthetic vision graphics

Image processing

Image enhancement, e.g. stabilization
Fusion of multiple sensors, e.g. image blending, image overlay
Integration with video analytics applications, e.g. intelligent motion detection, target tracking

Screen image operations

Live remote display
Recording
Playback

Applications

Unmanned vehicle systems

Manned and unmanned systems
Ground control systems
Distributed common ground system (DCGS)
Payload and analyst operator workstations

Naval C4ISR

UCAV/UCLASS EO/IR payload and analyst workstation
Command and control systems
Integrated bridge systems

Ground vehicles C4ISR

Situational awareness — 360° SA
Driver's video
Remote weapons sensor processing

This product is an option of the following products

SV-126

10" smart display

Article number: KX6336801000

SV-231

12" smart display

Article number: KX6336801200

DPM-3

Rugged Display Processing Module

Article number: K9395012

DPM-2

Rugged Display Processing Module

Article number: KX63355922

DPM-7700

High-performance ATC display server

Article number: KX633656

General

Library or standalone executable service
Operating systems: Linux and WindowsXP/XPe
Programming interface: C++ Library or url/http interface
Camera formats: NTSC/PAL/RS-170
Stream formats: MPEG2, MPEG4, H.264 via RTP and MotionJPEG2000
CUDA/OpenGL image processing and rendering
Up to 6 simultaneous camera inputs with 16 (or more) active video windows
Up to 5 simultaneous HD stream inputs with 5 (or more) active video windows

Performance using DPM-2E

Camera inputs:	3 cameras in 3 windows at 30fps with 2% CPU utilization
Streaming inputs:	· 4 720p streams in 4 windows at 30fps with 1% CPU utilization · 2 1080p streams in 2 windows at 30fps with 1% CPU utilization
Screen capture/recording:	· 1920x1200 desktop with 10% content change at · 15Hz with 10% CPU utilization
