Screen technology |
TFT AM LCD / S-IPS technology / LED backlight |
Active screen size (diagonal) |
611.3 mm (24") |
Active screen size (H x V) |
518.4 x 324 mm (20.4” x 12.7") |
Aspect Ratio |
16:10 |
Resolution |
1920 x 1200 |
Pixel pitch |
0.270 mm |
Color imaging |
Yes |
Color support |
1073 million (10-bit) |
Color gamut |
Wide gamut (Adobe RGB 1998) |
Viewing angle |
178° Hor / 178° Ver |
Maximum luminance |
350 cd/m² (typical) |
Contrast ratio |
1000:1 (typical) |
Response time |
6 msec (GtG - typ) |
Dot clock |
(max) 165 Mhz |
Gamma curve |
Native, 1.8, 2.0, 2.2, 2.4, DICOM |
Housing color |
White RAL 9003 |
Video inputs |
Video input signals:
-DVI-I Single-Link (Digital & Analog – HDMI video support with HDCP)
-Component Video RGBS / YPbPr (4xBNC)
-S-video (4-pin Mini DIN)
-Composite video (1xBNC)
-3G-SDI (1xBNC)
-DisplayPort (VESA std 1.1a)
-Optional: integrated BARCO Nexxis network adapter
Video input formats:
-VGA & DVI: Up to 1920x1200 at 60Hz (reduced blanking)
Maximum pixel clock: 165MHz
Maximum Hor freq: 90kHz
Maximum Ver freq: 75Hz
-Standard PAL and NTSC for S-Video, Composite and Component
-Component YPbPr/ RGBS: HDTV - up to 1080i & 1080p
-SDI Format Supported: 625/25 PAL, 525/29.97 NTSC, 1080i50, 1080i59.94, 1080i60, 720p50, 720p59.94, 720p60, 1080p50, 1080p59.94, 1080p60
-SDI Compliance: SMPTE 425M (Level A), SMPTE 424M, SMPTE 292M, SMPTE 259M-C, SMPTE 296M, ITU-R BT.656, ITU-R BT.601
-Displayport 1.1a: up to 1920 x 1200 60Hz |
Video outputs |
DVI-D
S-video (4-pin Mini DIN)
Composite video (1xBNC)
3G-SDI (1xBNC) |
Remote Control |
RS-232 (D-sub 9-pin) |
Power requirements (nominal) |
Power source for external power supply: 100 – 250 VAC / 47-63 Hz auto-switch
Power source for display power input: +24 VDC / 2.5A
Power supply for external module: +5VDC ±10% @500mA (max) through the DVI connectors DVI-in & DVI-out (on pin 14 or pin 16 - OSD programmable) |
Power management |
DVI-DMPM states supported
Power On state
Active-Off state |
Power consumption (nominal) |
less than 60 W (LED version) |
OSD languages |
English, French, German, Spanish, Italian |
Dimensions w/o stand (W x H x D) |
595 x 414 x 84 mm (23,4” x 16,3” x 3,3”) |
Net weight w/o stand |
7.7 kg (17.0 lbs) without power supply |
Net weight packaged w/o stand |
10.0 kg (22.0 lbs) |
Mounting standard |
100 x 100 mm VESA |
Screen protection |
IP21 / Front face: IPx5
Double coated, anti-reflective PMMA / White RAL 9003 |
Recommended modalities |
Endoscopy, laparoscopy, X-ray, CT, MR, US |
Regulation Compliance |
IEC60601 3rd Edition
Approvals/Marking: CE, C-UL-US, DEMKO, CCC
Safety (Medical equipment): IEC60601-1, UL60601-1, CSA-C22.2 nr 601-1-M90
Electromagnetic Compatibility: EMC Medical EMC Standards: IEC60601-1-2, EN55011 /CISPR 11, FCC CFR47 part 15 & 18/Class A
Environment: ROHS-2, REACH, WEEE compliant |
Temperature |
Operating: 0° - 40° C / Storage: -20° - 60° C |
Humidity |
Operating: 10% – 90% R.H. / Storage: 5% – 90% R.H. |
Keyboard/mouse |
Touch-sensitive, 7-key, backlit, bottom-right |
Supplied accessories |
User Manual, DVI Dual-Link cable 3.0m, Mains cables ( EU (CEBEC/KEMA) & US (Hospital grade UL)), External power supply |
Optional accessories |
Barco Surgical LCD Display Desk Stand, Barco MDSC Surgical Medical LCD Display Extension Cable 10m |
Warranty |
3 years |
