Screen technology |
a-si TFT active matrix |
Active screen size (diagonal) |
1473 mm (58.0") |
Active screen size (H x V) |
1270.08 x 721.44 mm (50 x 28.4") |
Aspect ratio (H:V) |
16:9 |
Resolution |
8MP (3840 x 2160) |
Pixel pitch |
0.33075 mm (H) x 0.334 mm (V) |
Color imaging |
Yes |
Color support |
16 million |
Viewing angle (H, V) |
88° |
Maximum luminance |
700 cd/m² (typical) |
Contrast ratio |
4000:1 (typical) |
Response time |
9.5 ms (typical) |
Housing color |
Black |
Video input signals |
DVI Dual Link |
Power requirements (nominal) |
90 ÷ 264 Vac 50Hz/60Hz |
Power consumption |
400 W (maximum) |
Power consumption |
35 W (stand-by) |
Power save mode |
Yes |
Dot clock |
260 MHz DVI dual link (preferred) |
Dimensions (W x H x D) |
Version w/o front glass: 1318.5 x 776 x 145.8 mm
Version with front glass: 1326.5 x 778 x 153.7 mm |
Dimensions packaged (W x H x D) |
1540 x 413 x 940 mm |
Net weight |
46 - 59 kg (depending on version) |
Net weight packaged |
68.5 - 83 kg (depending on version) |
Mounting standard |
VESA (400 mm) |
Screen protection |
Protective, non-reflective glass cover |
Recommended modalities |
Endoscopy, Laparoscopy, PACS, PM, US, CT, MR |
Certifications |
MDD 93/42/EEC, amended by 2007/47/EC Class I, IEC 60601-1:2005 + CORR. 1 (2006) + CORR. 2 (2007), EN 60601-1:2006 UL60601-1, 1st Edition, 2006-04-26, ANSI/AAMI ES 60601-1, 3rd edition:2005 EN 60601 3rd edition, CAN/CSA-C22.2 No. 601.1-M90, 2005, CAN/CSA-C22.2 No. 60601-1 (2008), IEC / EN 60601-1-2: 2007, EN 55011 / CISPR11 |
Supplied accessories |
User Guide |
Warranty |
2 years |
Operating temperature |
10-35°C for performance / 0-40°C for safety |
Storage temperature |
-20 ÷ +60°C |
Operating humidity |
10 ÷ 90% (non-condensing) |
Storage humidity |
10 ÷ 90% (non-condensing) |
Operating altitude |
3000m (maximum) |
|
12000m (maximum) |
