Active Display Area (mm) 1018.08 x 572.67
Resolution 1920 x 1080
Aspect Ratio 16:9
Display Colors 1.07B
Brightness (cd/m²; typ.) 500
Contrast Ratio 4000:1
Response Time (ms; GTG) 6.5
Viewing Angle 178°/178°
Lifetime (hours) 50,000
Backlight type LED
Touch Screen
Resolution 11456 x 6400
Response Time (ms) Touch : 10, Drawing : 15.2
Glass Transmission: 93%, Thickness: 5mm with anti-vandal
Available object size
for Touch (mm)
Touch : Ø 6
Stylus : Ø 7
Others USB 2.0 | Touch Intensity : Over 60,000,000 | Detection Method : Infrared Rays
Resolution
Monitor 1920 x 1080
DTV 1080p
Connectivity
Input 1x DVI | 1x HDMI | 1x VGA(D-Sub) | 1x PC Audio | 1x RS232C | 1x IR sensor
Output 1x DVI | 1x RS232C | 1x Audio Line out | 1x IR sensor
Power
Input Voltage 100 – 240V AC
Power consumption 110 W
Features
PIR Sensor (Motion detection) option
Built in speaker option
Auto Power Control yes
Auto Brightness Sensor no
Operation Temperature (ºC) 0 - 40
Humidity (%) 20 - 80
OSD Language 10 Lang
Dimension Set (W x H x D), mm TBD
Bezel Size (U/D/L/R), mm TBD
Wall Mounting (WxH), mm 400 x 400 / 600 X 400
Weight Set (kg) TBD
Resolution 1920 x 1080
Aspect Ratio 16:9
Display Colors 1.07B
Brightness (cd/m²; typ.) 500
Contrast Ratio 4000:1
Response Time (ms; GTG) 6.5
Viewing Angle 178°/178°
Lifetime (hours) 50,000
Backlight type LED
Touch Screen
Resolution 11456 x 6400
Response Time (ms) Touch : 10, Drawing : 15.2
Glass Transmission: 93%, Thickness: 5mm with anti-vandal
Available object size
for Touch (mm)
Touch : Ø 6
Stylus : Ø 7
Others USB 2.0 | Touch Intensity : Over 60,000,000 | Detection Method : Infrared Rays
Resolution
Monitor 1920 x 1080
DTV 1080p
Connectivity
Input 1x DVI | 1x HDMI | 1x VGA(D-Sub) | 1x PC Audio | 1x RS232C | 1x IR sensor
Output 1x DVI | 1x RS232C | 1x Audio Line out | 1x IR sensor
Power
Input Voltage 100 – 240V AC
Power consumption 110 W
Features
PIR Sensor (Motion detection) option
Built in speaker option
Auto Power Control yes
Auto Brightness Sensor no
Operation Temperature (ºC) 0 - 40
Humidity (%) 20 - 80
OSD Language 10 Lang
Dimension Set (W x H x D), mm TBD
Bezel Size (U/D/L/R), mm TBD
Wall Mounting (WxH), mm 400 x 400 / 600 X 400
Weight Set (kg) TBD
