| Display |
Screen Size (Diagonal) |
42-inch (1065 mm) |
| Panel Type |
IPS/Edge LED |
| Aspect Ratio |
16:09 |
| Effective Display Area (W x H) |
928 x 522 mm (36.5″ x 20.5″) |
| Number of Pixels (H x V) |
1920 x 1080 pixels |
| Brightness |
700 cd/m2 |
| Contrast Ratio |
1300;1 |
| Dynamic Contrast Ratio |
50000:1 |
| Response Time |
8 ms (G to G) |
| Viewing Angle (Horizontal/Vertical) |
178 ° / 178 °(CR≥10) |
| Connection Terminal |
Video In/Audio In (L/R) |
BNC x 1 set (shared with Component In) / Stereo Mini Jack (M3) x 1 (shared with Component In) |
| Component In/Audio In (L/R) |
BNC x 1 set (shared with Video In) / Stereo Mini Jack (M3) x 1 (shared with Video In) |
| HDMI IN |
TYPE-A connector x 2 |
| DVI-D IN/Audio In (L/R) |
DVI-D 24-pin x 1 / Stereo Mini Jack (M3) x 1 (shared with PC In) |
| DVI-D Out |
DVI-D 24-pin x 1 |
| PC IN/Audio In (L/R) |
Mini D-sub 15-pin x 1 / Stereo Mini Jack (M3) x 1 (shared with DVI-D In) |
| Audio Out |
Stereo Mini Jack (M3) x 1 |
| USB |
USB connector (TYPE A) x 1, DC 5 V/1 A |
| Control |
Serial In/Out |
D-sub 9-pin x 1/x 1, RS-232C compatible |
| LAN/Digital Link |
RJ45 x 1, 100BASE-TX, compatible with PJLink™ (shared with DIGITAL LINK) |
| IR In/Out |
Stereo Mini Jack(M3) x 1 / x 1 |
| Audio |
Built In Speaker |
20 W [10 W + 10 W] |
| Electrical |
Power Requirement |
110–127/220–240 V AC, 50/60 Hz |
| Power Consumption |
TBD |
| Power Off Condition |
Approx. 0.3 W |
| Stand-by Condition |
Approx. 0.5 W |
| Mechanical |
Dimensions (W x H x D) |
947 x 541 x 72 mm/37.3″ x 21.3″ x 2.8″ (TBD) |
| Bezel Width |
6.3 mm/0.25″ |
| Weight |
15.0 kg/33.1 lbs (TBD) |
| Wall-Hanging Pitch |
VESA Compliant 200 x 200 mm (7.9″ x 7.9″) |
| Environment |
Operating Environment |
Temperature |
Temperature: 0 °C to 40 °C (32 °F to 104 °F) / Humidity: 20–80 % (non-condensation) |
