Display Screen Size (Diagonal) 55-inch (1388 mm)
Panel Type IPS/Edge LED
Aspect Ratio 16:09
Effective Display Area (W x H) 1210 x 680 mm (47.6″ x 26.7″)
Number of Pixels (H x V) 1920 x 1080 pixels
Brightness 700 cd/m2
Contrast Ratio 1300;1
Dynamic Contrast Ratio 50000:1
Response Time 8 ms (G to G)
Viewing Angle (Horizontal/Vertical) 178 ° / 178 °(CR≥10)
Connection Terminal Video In/Audio In (L/R) BNC x 1 set (shared with Component In) / Stereo Mini Jack (M3) x 1 (shared with Component In)
Component In/Audio In (L/R) BNC x 1 set (shared with Video In) / Stereo Mini Jack (M3) x 1 (shared with Video In)
HDMI IN TYPE-A connector x 2
DVI-D IN/Audio In (L/R) DVI-D 24-pin x 1 / Stereo Mini Jack (M3) x 1 (shared with PC In)
DVI-D Out DVI-D 24-pin x 1
PC IN/Audio In (L/R) Mini D-sub 15-pin x 1 / Stereo Mini Jack (M3) x 1 (shared with DVI-D In)
Audio Out Stereo Mini Jack (M3) x 1
USB USB connector (TYPE A) x 1, DC 5 V/1 A
Control Serial In/Out D-sub 9-pin x 1/x 1, RS-232C compatible
LAN/Digital Link RJ45 x 1, 100BASE-TX, compatible with PJLink™ (shared with DIGITAL LINK)
IR In/Out Stereo Mini Jack(M3) x 1 / x 1
Audio Built In Speaker 20 W [10 W + 10 W]
Electrical Power Requirement 110–127/220–240 V AC, 50/60 Hz
Power Consumption TBD
Power Off Condition Approx. 0.3 W
Stand-by Condition Approx. 0.5 W
Mechanical Dimensions (W x H x D) 1229 x 699 x 72 mm/48.4″ x 27.5″ x 2.8″ (TBD)
Bezel Width 6.3 mm/0.25″
Weight 24.7 kg/54.5 lbs (TBD)
Wall-Hanging Pitch VESA Compliant 400 x 400 mm (15.8″ x 15.8″)
Environment Operating Environment Temperature Temperature: 0 °C to 40 °C (32 °F to 104 °F) / Humidity: 20–80 % (non-condensation)
