| Projector type |
Single-chip DLP projector |
| Technology |
LVDS DMD™ with DarkChip3™ |
| Resolution |
2,560 x 1,080 (Panorama) |
| Brightness |
3,800 ANSI lumens |
| Contrast ratio |
Up to 5,300:1 |
| Brightness uniformity |
>80% |
| Aspect Ratio |
21:9 |
| Lens type |
All pure glass lenses |
| Lenses |
Zoom EN51 (1.60-2.21:1), Wide Fixed EN52 (0.92:1), Ultra Wide Fixed EN53 (0.74:1), EN54 (2.5-3.9:1), Super Wide Zoom EN55 (0.86-1.16:1), Wide Zoom EN56 (1.14 – 1.74:1), Ultra Short Throw EN57 (0.3:1) |
| Optical lens shift |
Motorized. Range depends on the lens. |
| Color correction |
RealColor™ |
| Lamps |
1 x 350W UHP (dimmable) |
| Lamp lifetime |
Up to 2,000 hours (Full power) / 2,500 hours (eco mode) |
| Lamp house, quick replace |
Yes |
| Lamp warranty |
500 hours or 90 days |
| Sealed DLP™ core |
Yes |
| Orientation |
Table - ceiling (360 degrees through lamp axis) |
| 3D |
Yes, HDMI 1.4a |
| Inputs |
2x DisplayPort 1.2 (HBR2), 1 x DVI-Dual Link, 1 x HDMI 1.4a, 1 x VGA, 2x 3G-SDI, 1x HDBaseT |
| Input Resolutions |
2,560 x 1,600 - 640 x 480 pixel resolution, RGBHV, RGBS, RGsB, custom formats available, HDTV (1080p, 1080i, 720p), NTSC, PAL, SECAM |
| Software tools |
SimCAD, Projector Toolset |
| Control |
IR, RS232, Ethernet, USB |
| Network connection |
10/100/1000 base-T, RJ-45 connection, RS-232 |
| Power requirements |
100-240V / 50-60Hz |
| Power consumption |
less than 530W |
| Noise Level |
33dBA (full), 30dBA (eco mode), 25 dBA with full noise reduction kit |
| Operational ambient temperature |
10 - 40 °C /50 - 104 °F, 0-3,000m (Storage temperature: -20 - 60 °C/-4 - 140 °F) |
| Operating humidity |
20 - 80% RH (Storage Conditions: 10 - 90% RH) |
| Dissipation BTU |
max 1,807 BTU/h |
| Dimensions (WxLxH) |
342 x 306 x 143 mm / 13.46 x 12.05 x 5.63 inches |
| Weight |
7.5 kg (16.5 lbs) |
| Standard accessories |
Power cord, wireless remote control |
| Certifications |
Compliant with FCC, part 15 Class A and CCC, cCSAus, cUL, UL and CE |
| Warranty |
Limited 3 years parts and labor. Extendable up to 5. |
