Specifically for training and simulation, the F35 series projector is also available for night vision stimulation through IR (Infrared). Featuring special high contrast lenses, the F35 is a great solution when high brightness is required for daytime scenarios and great black levels and high contrast IR for night training.
All F35 series projectors benefit from Barco’s proprietary and highly accurate RealColor color management technology. The F35 series guarantee the right colors at any time and support REC709 color space. From factory, each projector is programmed with its individual abilities stored in its memory.
In addition to the continuous operation mode, lamps can be replaced whilst the projector is operating. Should lamps need replacement or fail during a presentation, the projector will continue running.
Because we make the world’s highest resolution projectors, we also design and manufacture the world’s highest resolution projection lenses. All lenses have an all-glass design using floating aspherical lens elements and ND glass. In combination with high F-numbers this results in great focus sharpness and a wide focus depth while maintaining an unmatched high ANSI contrast. A dedicated range of lenses optimized for IR (Infrared) support is also available.
All F35 series projectors feature flicker-free Smear Reduction Processing - SRP™ so that no external filters or shutters are needed - all processing is not only done internally, it’s also fully adjustable and configurable. Combined with high frame rates up to 120 Hz, this ensures a smear-free image at any resolution and with fast-moving content.
| Technology | single chip DLP® projector LVDS DMD™ with DarkChip3™ |
|---|---|
| Concept | single chip, powered lens shift system |
| 3D capability | INFITEC EX® 3D and Active Stereo |
| 3D glasses compatibility | IR, RF models, DLPLink™ |
| Color wheel | High Brightness / VizSim Bright / VizSim |
| Resolution | WQXGA (2,560 x 1,600), Panorama (2,560 x 1,080), WUXGA (1,920 x 1,200), 1080p (1,920 x 1,080) |
| Brightness | Up to 7,500 lumens (typical brightness, this can vary depending on the used color wheel and lens) |
| Contrast | Up to 8,000 : 1 (Contrast varies based on settings, color wheels, and lens) |
| Aspect Ratio | 16:10 (WQXGA), 21 : 9 (2.37 : 1) (panorama), 16:10 (WUXGA), 16:9 (1080p) |
| Display colors | 30-bit RGB |
| Latency | ~19 ms |
| Computer graphics formats | Up to 2,560 x 1,600 pixels input on all models. Output resolution depends on native resolution. AS3D compatible with WUXGA and 1080p models only. |
| Horizontal scan frequencies | 10 - 150kHz |
| Vertical scan frequencies | 48 - 190 Hz (resolution dependant) |
| Video formats | HDTV (1080p, 1080i, 720p), EDTV (576p, 480p), SDTV (576i, 480i), NTSC, PAL, SECAM, progressive scan |
| Lens operation | Motorized zoom, Focus, Shift, Iris and Mechanical shutter |
| Image width | 0.5 - 10 m |
| Light source | 2 x 300W UHP VIDI |
| Lamp lifetime | Up to 2,000 hours (Full power) / Up to 2,500 hours (Eco mode) |
| Computer inputs | 2 x DVI-I, 2 x HDMI 1.3a, 2 x VGA |
| Video Input | 1 x Component, 1 x S-video |
| Control possibilities | 1 x RJ-45 TCP/IP, 1 x 9-pin D-SUB RS232, 2 x 12V programmable trigger (3.5mm mini jack), 1 x Wired Remote 3.5mm mini jack, 2 x USB |
| Dimensions | 510 x 223 x 376 mm (WxHxD) |
| Weight | 12.7 kg |
| Shipping Dimensions | 780 x 370 x 520 mm (WxHxD) |
| Shipping Weight from Factory | 20 kg |
| Power requirements | 8.4A ~100-240V 50-60Hz, typical consumption: Max 815W@100V |
| Conformances | CCC, cCSAus, FCC Class A, cUL, UL and CE |
| Operating temperature | 10 - 40 °C |
| Storage temperature | -20 - 60 °C |
| Operating humidity | 20 - 80% RH |
| Storage humidity | 10 - 90% RH |
| Color | Black metallic |
| Warranty | 3 years, 500 hours or 90 days on lamp (whichever comes first). Up to 5 years total warranty available: Conditions apply. |
| 24-7 documentation | This projector is designed and warranted for heavy duty 24/7 operation. Specific measures and design considerations have been made in order for it to comply with stringent requirements in challenging applications. |
| MTBF | 34,662 hours |
| BTU per hour | less than 3,109 |
