Projection System: 3LCD, 3-chip technology
Projection Method: Front / rear / ceiling mount
Product Color: White
Driving Method: Poly-silicon TFT Active Matrix
Projected Output: 720p (1280 x 720 HDMI)
Pixel Number: 1,024,000 (1280 x 800) x 3
Color Brightness (Color Light Ouput): 3000 lumens1
White Brightness (White Light Output): 3000 lumens1
Aspect Ratio: Native 16:10 widescreen
Native Resolution: WXGA (1280 x 800)
Resize: 4:3, 16:9
Lamp Type: 200 W UHE
Lamp Life:
- ECO mode: Up to 6000 hours2
- Normal mode: Up to 5000 hours2
Throw Ratio Range: 1.30 (Zoom: Wide) – 1.56 (Zoom: Tele)
Size (projected distance): 33" – 318"
Keystone Correction:
- Vertical: ±30 degrees (Auto)
- Horizontal: ±30 degrees (Slide bar)
Contrast Ratio: Up to 12,000:1
Color Reproduction: Up to 1.07 billion colors
Color Processing: 10 bit
Other
Display Performance: WXGA native 720p; HD, 2D
Color Modes: Dynamic, Living room, Cinema, Game
Input Signal: 480i / 576i / 480p / 576p / 720p / 1080i / 1080p / HDMI: TMDS
Terminal Inputs:
- 1 HDMI
- 2 RCA (1 audio L/R)
- 1 S Video
- 1 VGA D-sub 15 pin (computer input)
- 1 USB Type A
- 1 USB Type B
Video Compatibility: WXGA, SXGA, XGA, SVGA, VGA, WSXGA, UXGA
Speaker: 2 W Mono
Operating Temperature: 41° to 95° F (5° to 35° C)
Power Supply Voltage: 100 – 240 VAC ±10% , 50/60 Hz
Power Consumption:
- ECO mode: 207 W
- Normal mode: 283 W
- Communication on: 2.9 W standby
- Communication off: 0.24 W
Fan Noise: 29 dB – 37 dB
Security: Kensington Security Lock Port
Notes
1 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.
2 Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
Epson Home Entertainment projectors have up to 3x Brighter Colors than their leading competitive 1-chip DLP Home Entertainment Projectors. Epson 720p projectors are 3x Brighter; Epson 1080p projectors are consistently 2x and up to 3x Brighter. Based on NPD data, July 2011 through June 2012. Color brightness (color light output) measured in accordance with IDMS 15.4. Color brightness will vary depending on usage conditions.
