Optyka
-
Wyświetlacz
0.67" (16:10 aspect ratio) DLPx1
-
Rozdzielczość
WUXGA (1920 x 1200)
-
Jasność
10000 ANSI Lumens (Normal Mode) / 7500 ANSI Lumens (Eco Mode)
-
Współczynnik kontrastu
2500:1
-
Obiektyw
Interchangeable, Powered Zoom, Powered Focus, Lens shift
-
Moc lampy
430W Dual (Normal) / 344W Dual (ECO)
-
Trwałość lampy
2000 godzin (tryb zwykły)/4000 godzin (tryb eko)*
-
Współczynnik odległości do szerokości
1.6 (WIDE), 2.4 (TELE) (Standard Lens SD-903 not included)
-
Przekątna obrazu
50"~600" (100" at 3.5m, wide max.)
-
Liczba kolorów
16.7 million colours
-
Ogniskowa
1.8m~21.4m (WIDE) / 2.7m~31.9m (TELE) (Standard Lens SD-903 not included)
-
Korekcja geometrii obrazu
Vertical 11:-1, Normal at +12.9°~+8.7° projection angle
-
Zgodność
-
Computer compatibility
IBM Compatible VGA, SVGA, XGA, WXGA/WXGA+/SXGA/SXGA+/WSXGA+/UXGA/WUXGA (compressed), MAC16"
-
Composite Video
NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43
-
Component Video
525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 1125p(1080p@50/60), 750p(720p@50/60)
-
HDMI/HDBaseT/SDI
525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60), 750p(720p@50/60), 1125p(1080p@50/60)
-
Cechy i funkcje
-
Podstawowe funkcje
Auto signal search & Source skip,Frame Lock,Image blank by RS232C/Remote control LED lamps (Filter, Shutter, Security, Lamp-1, Lamp-2, Temp, Power),Mechanical shutter, Magnify, Mirror Reverse Image, Up-side Down Image, Freeze, Serial number displayed on EASY MENU and on the side of projector, Status monitoring by sub LCD
-
Picture Adjustments
Bright/Rich Colour, Accentualizer and HDCR, Equalizing Colour temperature adjustment, Equalizing Digital Gamma Correction, Picture mode (Standard, Natural, Cinema, Dynamic, Board (Black), Board (Green), Whiteboard, Daytime, DICOM Simulation, User-1, User-2, User-3), Resolution setting, Video noise reduction, Mirror Reverse Image, Up-side Down Image, My Button by Remote control, My Memory, My source, My Text, MyScreen
-
Cyfrowa korekcja trapezu
Horizontal & Vertical ± 30 degrees
-
Advanced Features
360 degree installation angle, Active Iris,Blending/Cropping,Filter timer / selectable interval time to show the message for air filter cleaning,Image blank by RS232C/Remote control,Lens memory (Lens shift position, Lens type) MAC address displayed on the side of projector,Magnify 4 times (XGA) by RS232C/ Remote control, Mechanical shutter, Overscan (Video, Component video signal), Perfect Fit (4 corners), capable of saving/loading the setup, Picture by Picture/Picture in Picture, Magnify 4 times (XGA) by RS232C/Remote control, Portrait projection,Resolution setting,Warping and Blending Simultaneously, Scheduling features, 24/7 Dual Lamp mode
-
Włączanie i wyłączanie
Auto Power off, Direct power on, Eco mode
-
Security Systems
PIN Security Lock, MyScreen Password Lock, My Text Password Lock, Lens Lock, Key Lock (Key pad, Remote Control)
-
Sieć
AMX Device Discovery, Command Control via the Network, Configuring and Controlling the Projector via a Web Browser, Controlling the Projector via Scheduling Crestron RoomView® (Not accessible through the wireless adapter), Displaying text data transferred via network, Extron XTP system, Failure and Warning Alerts via E-mail, My Image (still image transfer) Display, Network Bridge, Network Presentation (PC still picture transfer), Frame rate (practical) is under 12fps (640x480 movie) reference purpose only, PJLinkTM, Projector Management via SNMP
-
Języki menu ekranowego
33
