Display Technology Single 0.65” 1080p chip, DLP® Technology from Texas Instruments™
Resolution 1080p 1920 x 1080
Brightness 5000 Lumens
Contrast Ratio 15000:1
Lamp Life2 (hrs)
Throw Ratio 3 1.41~2.24:1 (distance/width)
Keystone Correction ±30° Vertical and Horizontal
Weight 10.2 lb (4.6 kg)
Dimensions (W x D x H) 14.5" x 12" x 5.2"
Aspect Ratio 16:9 (native), 4:3, Auto
Offset 99% to 116% (+/- 5% variance)
Projection Screen Size 26.2"~301.1" (diagonal)
Projection Distance 51.18"–370"
Projection Lens F=2.5~3.26, f=20.913~32.626mm - manual zoom and focus
Uniformity 70%
Maximum Resolution 1080p (1920 x 1080)
Computer Compatibility UXGA, SXGA, XGA, SVGA, VGA, WXGA,1080p, Mac
Video Compatibility PAL (B, D, G, H, I, M, N, 4.43MHz), NTSC (M, J, 3.58MHz, 4.443MHz), SECAM (B, D, G, K, K1, L, 4.25,MHz, 4.4MHz, 480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz) 1080p(24/50/60Hz)
3D Compatibility Side-by-Side:1080i50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-Under: 1080p24, 720p50 / 60
Horizontal Scan Rate 15.375–91.146 KHz
Vertical Scan Rate 24–85 Hz (120 Hz for 3D feature projector)
Displayable Colors 1.07 Billion
Power Supply AC input 100–240V, 50–60 Hz, auto-switching
Power Consumption 421W Max (Bright), 329W Max (ECO)
Operating Conditions Operating Temp @ Sea Level to 10000 feet = 23°C (max); must manually switch to high altitude mode @ 5000 feet & above (using OSD)
Remote Control SP.72702GC01
Optional Wireless No
Warranty 3 Years
Projection method Front, rear, ceiling mount, table top
Warranty 3-Year Optoma Express Service, 1-Year on Lamp
1Lamp based projectors brightness and lifetime will vary depending on selected projector mode, environmental conditions and usage. As is common with all lamp based projectors, brightness will decrease over the lamp lifetime. LED projectors do not have a replaceable lamp and the brightness does not decay significantly over the product lifetime.
2Typical lamp life achieved through testing. Will vary according to operational use and environmental conditions
3 +/- 5% tolerance
