TECHNICAL SPECIFICATIONS
Aspect Ratio 16:9
Audio 3W Speaker
Brightness 3,600 ANSI lumens
Color Wheel 6 segment RYGCWB
Compatible Aspect Ratio 16:9 (native), 4:3, 16:10 and LBX compatible
Connections HDMI (1.4a), audio out (3.5mm), USB (1.5a / firmware update)
Contrast Ratio 25,000:1
Control Unit Complete on-screen menu adjustment in 26 languages
Display Technology Texas Instruments 0.47” DMD
Displayable Colors 1.07 billion
Image Size 28” – 301"
Keystone Correction ±40° Vertical
Light Source Type 240W
Light Source Life 15,000/10,000/4,000 (Dynamic/Eco/Bright)
Maximum Resolution WUXGA (1920×1200)
Native Resolution 1080p (1920×1080)
Noise Level 26dB
Offset 116%±5%
On-Screen Display Complete on-screen menu adjustments in 26 languages
Operating Temperature 41–104°F (5–40°C), 85% max humidity
Power Consumption 295W typical (Bright), 325W max (Bright), 215W typical (Eco), 240W max (Eco)
Power Supply AC input 100 – 240V, 50 – 60 Hz, auto-switching
Projection Distance 3.2’ – 35.37” (no zoom)
Projection Lens F=2.1 ~2.31, f=15.59 ~ 17.14mm manual
Projection Method Front, rear, ceiling count, tabletop
Projection Screen Size 28” – 301"
Remote Control Full size remote
Throw Ratio 1.47 – 1:62 (+/- 5% variance)
Uniformity 80%
Zoom Type 1.1x optical, 0.8 – 2.0 digital
COMPATIBILITY SPECIFICATIONS
Computer Compatibility FHD, HD, WXGA, UXGA, SXGA, XGA, SVGA, VGA, Mac
Horizontal Scan Rate 25 – 85Hz (120Hz for 3D)
Optional Wireless No
RoHS Compliant
Vertical Scan Rate 15 – 91kHz
Video Compatiblity PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080i, 720p)
PHYSICAL SPECIFICATIONS
Dimensions (W x H x D) 12.4” x 4.3” x 9.5”
Security Security bar, Kensington lock, password protection
Weight 6.2 lbs.
OTHER
Optional Accessories Universal ceiling mount, lamp, remote
Standard Accessories AC power cord, remote control, batteries for remote, quick start guide
UPC 796435 81 366 6
Warranty Info 1-Year parts and labor limited warranty on the projector, 90 days lamp warranty
