Display Technology |
Single 0.65” WXGA DC3 DMD chip DLP® Technology by Texas Instruments |
Resolution |
WXGA 1280 x 800 |
Brightness1 (Bright Mode) |
3400 ANSI Lumens |
Contrast |
18,000:1 |
Typical lamp life2 Eco+/Dynamic/Eco/Bright/Education cycle |
8000/7000/6000/5000/10000 (hrs) |
Throw Ratio 3 |
1.19 – 1.54:1 |
Zoom Type |
1.3x Manual |
I/O Connectors |
2x HDMI (1.4a 3D support) + MHL v2.1, 2x VGA (YPbPr/RGB), S-Video, Composite, 2x Audio In 3.5mm, VGA out, Audio Out 3.5mm, RS232, RJ45, USB-A Power (1A) |
Speaker |
16 |
Keystone Correction |
± 40° Vertical |
Weight (kg) |
2.52 |
Dimensions (W x D x H) (mm) |
298 x 230 x 96.5 |
Aspect Ratio |
16:10 Native, 16:9/4:3 Compatible |
Offset |
115% |
Projection Screen Size |
0.92 – 7.65m (36.1" to 301.1") Diagonal 16:10 |
Projection Distance |
1.2 - 7.7m |
Projection Lens |
F/2.5~2.78; f=16.91~21.6mm |
Uniformity |
75% |
Computer Compatibility |
FHD, HD, WXGA, UXGA, SXGA, XGA, SVGA, VGA, Mac |
Video Compatibility |
PAL (B, D, G, H, I, M, N, 4.43MHz), NTSC (M, J, 3.58MHz, 4.443MHz), SECAM (B, D, G, K, K1, L, 4.25,MHz, 4.4MHz, 480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz) 1080p(24/50/60Hz) |
3D Support |
Full 3D - The 3D features of Optoma projectors can only be used with compatible 3D content. Typical applications include use with 3D educational or 3D design and modelling systems. 3D TV broadcast systems, (SKY in the UK), Blu-ray 3D™ and 3D games from the Sony® PS3 or Microsoft® Xbox 360 are now supported as part of the HDMI v1.4a specification. |
3D Compatibility |
Side-by-Side:1080i50 / 60, 720p50 / 60
Frame-pack: 1080p24, 720p50 / 60
Over-Under: 1080p24, 720p50 / 60 |
Horizontal Scan Rate |
15.3 - 91.1kHz |
Vertical Scan Rate |
24 - 85Hz (120Hz for 3D) |
Displayable Colours |
1073.4 Million |
Noise Level (Eco mode) |
29dB |
Power Supply |
100-240V, 50-60Hz |
Power Consumption |
225W Bright mode / 187W Eco mode (< 0.5W Standby) |
Lamp Type |
195W |
Operating Conditions |
5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m |
Security |
Security bar, Kensington lock, password protection |
On Screen Display |
26 Languages: English, German, French, Italian, Spanish, Portuguese, Swedish, Dutch, Norwegian/Danish, Polish, Russian, Finnish, Greek, Hungarian, Czech, Arabic, Traditional Chinese, Simplified Chinese, Japanese, Korean, Thai, Turkish, Farsi, Vietnamese, Romanian, Indonesian |
Standard Accessories |
AC power cord, remote control, 2x AAA batteries, quick start card, CD user manual |
Optional Accessories |
DLP® Link™ 3D glasses, wireless, ceiling mount |
Optional Wireless |
Yes |
RoHS |
Compliant |
