Dane techniczne
Display System
Display System4K SXRD panel, projection system
Size of effective display area0.74” x 3
Number of Pixels26,542,080 (4096 x 2160 x 3) pixels
Projection Lens *1
FocusPowered
ZoomPowered
Light Source
Light SourceLaser phosphor
Light Output
Light Output10,000lm
Color Light Output
Color Light Output10,000lm
Contrast Ratio (Native)
Contrast Ratio (Native)Typical 16,000 : 1 *2
Accepted Digital Signals
Accepted Digital Signals1920 x 1080/24p, 1920 x 1080/50p, 1920 x 1080/60p, 1920 x 1080/100p, 1920 x 1080/120p, WQHD/60p, WQHD/120p, QXGA/60p, QXGA/120p, WQXGA/60p, WQXGA/120p, 3840 x 2160/50p, 3840 x 2160/60p, 3840 x 2160/100p *3, 3840 x 2160/120p *3, 4096 x 2160/50p, 4096 x 2160/60p, 4096 x 2160/100p *3, 4096 x 2160/120p*3
Color Bit Depth
Color Bit DepthUp to 12 bit via HDMI / Up to 10 bit via Display Port
INPUT OUTPUT (Computer / Video / Control)
HDMI2 inputs (HDCP 2.3), Digital (RGB/Y Pb/CbPr/Cr)
Display Port2 inputs (Ver. 1.4, HDCP 2.3), Digital (RGB)
TRIGGER2 connectors, Mini jack, DC 12V Max.100 mA
REMOTERS-232C, D-sub 9-pin (male)
LANRJ45, 10BASE-T/100BASE-TX
IR IN/OUTIN:1, Out:1, Mini jack
3D SYNC OUT3-pin mini-DIN (VESA 3D)
USBType A, DC 5 V, Max. 500 mA
OSD Languages
OSD Languages18-languages (English, Dutch, French, Italian, German, Spanish, Portuguese, Turkish, Russian, Swedish, Norwegian, Japanese, Simplified Chinese, Traditional Chinese, Korean, Thai, Arabic, Polish)
Acoustic Noise
Acoustic Noise33 dB ~ 39 dB *2
Operating Temperature / Operating Humidity
Operating Temperature / Operating Humidity5℃ to 40℃ (41°F to +104°F)/20% to 80% (no condensation)
Storage Temperature / Storage Humidity
Storage Temperature / Storage Humidity-10℃ to + 60℃ (14°F to +140°F)/20% to 80% (no condensation)
Power Requirements
Power RequirementsAC 200 V to 240 V, 50/60 Hz
AC 100 V to 120 V, 50/60 Hz *4
Power Consumption
Power ConsumptionMAX. 2.0 kW
Power Consumption (Standby Mode)
Power Consumption (Standby Mode)0.5 W
Heat Dissipation
Heat Dissipation4092 BTU/h
Dimensions (W x H x D)
Dimensions (W x H x D)560 x 228 x 760 mm (22 1/16 x 8 31/32 x 29 15/16 in) (without protrusions)
560 x 262 x 760 mm (22 1/16 x 10 5/16 x 29 15/16 in)
Mass
MassApprox. 51 kg / 112 lb (excluding lens)
Supplied Accessories
Supplied AccessoriesRM-PJ29 Remote Commander (1), Size AA (R6), Manganese Batteries (2), AC Power Cord (1), Plug Holder (1), Operating Instructions (CD-ROM) (1), Safety Regulations (1)
Notes
*1The lenses are optional accessories.
*2This value is approximate. Depends on the projector setting condition and usage environment.
*3Optional license, LSM-120P1, is required to accept the signal.
*4Brightness is dimmed.
