Specyfikacja techniczna
Image Display
- Display System: 3-Chip 0.74" SXRD LCoS
- Native Chip Resolution: 4096 x 2160 (DCI 4K)
- Max Brightness: 2200 Lumens
- Aspect Ratio: Native: 17:9
- DLP Link 3D: Yes
Lens
Focus
Manual Powered
Lens Shift
Vertical: ± 80%
Horizontal: ± 31%
Optical Zoom
Powered: 2.1x
Throw Ratio
1.35 - 2.9:1
Projection Size
60 - 300" / 152.40 - 762.00 cm
Features
Input/Output Connectors
Inputs/Outputs
2 x HDMI (HDMI Type-A) Audio, Video Input
1 x Ethernet (RJ45) LAN
1 x 1/8" (3.5 mm) Mini Control Input
2 x 12 V Trigger Control Output
1 x RS-232C (DE-9) Control
1 x USB 2.0 (USB Type-A) Service Input
Memory Card Slot
None
General
Light Source
Laser Phosphor
Lamp Power
343 W
Expected Lamp Life
Medium Brightness: 20,000 Hours
Fan Noise
Medium Brightness: 26 dB
AC Input Power
100 to 240 VAC, 50 / 60 Hz
Power Consumption
Full Brightness: 490 W
Standby Mode (Lamp Off): <1 W
Operating Temperature
41 to 95°F / 5 to 35°C
Storage Temperature
10 to 140°F / -12 to 60°C
Operating Humidity
20 - 80%
Storage Humidity
20 - 80%
Dimensions (W x H x D)
22.0 x 9.1 x 20.1" / 560.0 x 230.0 x 510.0 mm With protrusions
22.0 x 8.8 x 19.5" / 560.0 x 223.0 x 496.0 mm Without protrusions
Weight
48.5 lb / 22.00 kg
Special Features: Anamorphic Ready, Full HD 3D, Frame Interpolation, Lens Memory, HDR, Infinite Black
